Details
(1) The product adopts the original Permco motor from USA, its vibration is a few times as the vibrating plate compactor. The degree of compaction can meet the high grade basic requirements of highway, railway, watercourse , reservoir and such like that because of the high striking force.
(2) It is used for plane, cant, step, trench and pits, or any other complicated compaction and local tamping
(3) Widely used in road shoulder, side slope, railway, dam, foundation etc.
(4) High-intensity wear-assistance plate is adopted to guarantee the quality of the product.
|
型号Model |
Unit |
Mini |
JXZ 300 |
JXZ 600 |
JXZ 800 |
JXZ 1000 |
|
打击力 |
ton |
3 |
4 |
6.5 |
15 |
20 |
|
振动次数 |
Rpm |
2000 |
2000 |
2000 |
2000 |
2000 |
|
使用油量 |
L/min |
28-35 |
45-75 |
85-105 |
120-170 |
120-170 |
|
压力 |
Kg/cm2 |
100-130 |
100-130 |
100-130 |
150-200 |
160-240 |
|
重量 |
kg |
250 |
270 |
500 |
900 |
1200 |
|
打击面积 |
(L*W) |
750*1050 |
900*500 |
1160*700 |
1350*900 |
1500*1000 |
|
总高 |
mm |
680 |
760 |
920 |
1060 |
1200 |
|
总宽 |
mm |
450 |
550 |
700 |
900 |
1000 |
|
适配挖机 |
ton |
2-4 |
4-9 |
11-16 |
17-23 |
30-50 |
